Welded standard hollow rod hydraulic cylinder

Dahong Hydraulic is a powerful enterprise that integrates the research and development, production, and sales of hydraulic cylinders. The products mainly cover hydraulic cylinders for rock drilling rigs, tunneling machines, railway equipment, and so on. Hydraulic cylinders have the characteristics of high power density, smooth motion, high-precision control, high reliability, and excellent structural design.

Model:

K.039.341.YG

17706179858

shaominjiao@wxdahong.com

E-mail

Online Message

Product Details


ΦD bore diameter	Φd rod diameter	EE screw thread	A	B	C	ΦF	G	L	M	ΦP	R	N	H
Φ50	Φ35	G3/8	45	40	70	Φ65	60	282	30	Φ30	32.5	30	120
Φ63	Φ40/Φ35	G3/8	55	50	70	Φ76	60	320	35	Φ30	40	35	130
Φ70	Φ45/Φ40	G3/8	60	50	80	Φ85	70	347	45	Φ35	40	45	140
Φ80	Φ55/Φ45	G3/8	70	60	90	Φ95	80	380	45	Φ40	50	45	150
Φ90	Φ55/Φ45	G3/8	70	60	100	Φ108	90	400	50	Φ45	50	50	160
Φ100	Φ55/Φ63	G3/8	80	70	110	Φ118	100	418	60	Φ50	60	60	170
Φ110	Φ80/Φ63	G3/4	85	75	130	Φ130	110	442	65	Φ60	65	65	200
Φ125	Φ90	G3/4	90	80	150	Φ146	125	470	70	Φ70	70	70	220
