Rotary cylinder

Dahong Hydraulic is a powerful enterprise that integrates the research and development, production, and sales of hydraulic cylinders. The products mainly cover hydraulic cylinders for rock drilling rigs, tunneling machines, railway equipment, and so on. Hydraulic cylinders have the characteristics of high power density, smooth motion, high-precision control, high reliability, and excellent structural design.



Product Details

25MPA标准油缸80-45-100 - 图纸1.jpg

ΦD

bore diameter

Φd

rod diameter

EE

screw thread

ABDCΦFGLMΦpR  h
Φ40Φ28/Φ25M14X1.5/(G1/4)28354442Φ505619030Φ202515
Φ50Φ35/Φ32/Φ28M14X1.5/(G1/4)35405456Φ656122030Φ2532.515
Φ63Φ45/Φ40/Φ35M18X1.5/(G3/8)45506556Φ768325335Φ304015
Φ70Φ50/Φ45/Φ40M18X1.5/(G3/8)45506664Φ858727945Φ354015
Φ80Φ55/Φ50/Φ45M22X1.5/(G1/2)50557169Φ959529750Φ404518
Φ90Φ63/Φ55/Φ50M22X1.5/(G1/2)55607769Φ10810030855Φ455018
Φ100Φ70/Φ63/Φ55M27X2/(G3/4)69709073Φ11811335160Φ506020
Φ110Φ80/Φ70/Φ63M27X2/(G3/4)75759673Φ13012036270Φ606520
Φ125Φ90/Φ70M27X2/(G3/4)808010178Φ14612738670Φ607020
Φ130Φ90M27X2/(G3/4)808010182Φ15212839170Φ607020
Φ140Φ80/Φ100M27X2/(G3/4)909011195Φ16513242780Φ708020
Φ150Φ85/Φ105M27X2/(G3/4)9010012295Φ18014845390Φ809020
Φ160Φ90/Φ110M27X2/(G3/4)9010012295Φ19014846890Φ809020
Φ180Φ100/Φ125M27X2/(G3/4)95110139100Φ210165500100Φ9010020
Φ200Φ110/Φ140M33X2/(G1)110120139100Φ235179540110Φ10011022
