200 ton hydraulic cylinder

Dahong Hydraulic is a powerful enterprise that integrates the research and development, production, and sales of hydraulic cylinders. The products mainly cover hydraulic cylinders for rock drilling rigs, tunneling machines, railway equipment, and so on. Hydraulic cylinders have the characteristics of high power density, smooth motion, high-precision control, high reliability, and excellent structural design.

Model:

K.040.103.YG

13665121168

shaominjiao@wxdahong.com

E-mail

Online Message

Product Details

25MPA标准油缸80-45-100 - 图纸1.jpg

ΦD bore diameter	Φd rod diameter	EE screw thread	A	B	D	C	ΦF	G	L	M	Φp	R	h
Φ40	Φ28/Φ25	M14X1.5/(G1/4)	28	35	44	42	Φ50	56	190	30	Φ20	25	15
Φ50	Φ35/Φ32/Φ28	M14X1.5/(G1/4)	35	40	54	56	Φ65	61	220	30	Φ25	32.5	15
Φ63	Φ45/Φ40/Φ35	M18X1.5/(G3/8)	45	50	65	56	Φ76	83	253	35	Φ30	40	15
Φ70	Φ50/Φ45/Φ40	M18X1.5/(G3/8)	45	50	66	64	Φ85	87	279	45	Φ35	40	15
Φ80	Φ55/Φ50/Φ45	M22X1.5/(G1/2)	50	55	71	69	Φ95	95	297	50	Φ40	45	18
Φ90	Φ63/Φ55/Φ50	M22X1.5/(G1/2)	55	60	77	69	Φ108	100	308	55	Φ45	50	18
Φ100	Φ70/Φ63/Φ55	M27X2/(G3/4)	69	70	90	73	Φ118	113	351	60	Φ50	60	20
Φ110	Φ80/Φ70/Φ63	M27X2/(G3/4)	75	75	96	73	Φ130	120	362	70	Φ60	65	20
Φ125	Φ90/Φ70	M27X2/(G3/4)	80	80	101	78	Φ146	127	386	70	Φ60	70	20
Φ130	Φ90	M27X2/(G3/4)	80	80	101	82	Φ152	128	391	70	Φ60	70	20
Φ140	Φ80/Φ100	M27X2/(G3/4)	90	90	111	95	Φ165	132	427	80	Φ70	80	20
Φ150	Φ85/Φ105	M27X2/(G3/4)	90	100	122	95	Φ180	148	453	90	Φ80	90	20
Φ160	Φ90/Φ110	M27X2/(G3/4)	90	100	122	95	Φ190	148	468	90	Φ80	90	20
Φ180	Φ100/Φ125	M27X2/(G3/4)	95	110	139	100	Φ210	165	500	100	Φ90	100	20
Φ200	Φ110/Φ140	M33X2/(G1)	110	120	139	100	Φ235	179	540	110	Φ100	110	22
